This manual is the safety instruction manual for Omron frequency inverter 3G3MZ, which includes precautions before use, safety precautions, environmental requirements, transportation, installation, wiring, maintenance and cleaning.
This manual covers safety precautions, installation, wiring, operation, monitoring, trial run, basic and application operation, communication setup, and maintenance for the SYSDRIVE 3G3MZ series. It includes detailed parameter tables and optional expansion modules.
The document also lists environmental limits, input voltage options, power ratings, and recommended accessories, helping users configure the drive safely and efficiently. This manual is written in Chinese.
| Operating temperature range | -10 °C to +50 °C (‑10 °C to +40 °C for compact installation) |
|---|---|
| Maximum relative humidity | ≤ 90 % |
| Input voltage (single‑phase) | 200‑240 VAC, 50/60 Hz |
| Input voltage (three‑phase, 200 V type) | 200‑240 VAC, 50/60 Hz |
| Input voltage (three‑phase, 400 V type) | 380‑480 VAC, 50/60 Hz |
The device can operate from –10 °C up to +50 °C, or –10 °C to +40 °C when installed compactly.
It supports single‑phase 200‑240 VAC, three‑phase 200‑240 VAC, and three‑phase 380‑480 VAC, all at 50/60 Hz.
