This document introduces the models and characteristics of AC drives and servo motors, including the R88D-GT-Z, R88D-GN-ML2-Z, and R88M-G-Z series, with power ranging from 50W to 7.5kW. The document also provides technical specifications and descriptions of the products.
This manual provides safety instructions, warranty information and installation guidelines for Omron's OMNUC G series AC servo motor drivers ranging from 50 W to 7.5 kW. It explains how to connect the driver, set parameters via a single cable, and integrate it with Omron CX‑One and MECHATROLINK‑I communication systems.
The document also lists technical specifications such as power range, supply voltage, maximum speed and mechanical clearances, and includes tables for model numbers, reduction gear options and wiring diagrams. This manual is written in Chinese.
| Power range | 50 W‑7.5 kW |
|---|---|
| Supply voltage | AC100 V / AC200 V |
| Maximum speed (7.5 kW model) | 1500 r/min |
| Maximum radial gap | 15 mm |
The warranty period is one year from the date of delivery at the specified location.
The driver includes built‑in MECHATROLINK‑I communication.
All required parameters can be set using just one cable.
The maximum speed is 1500 r/min.
