This document introduces a small relay G6D, which has the characteristics of high-density installation and small size. The relay can achieve a switching capacity of 5A and a high life of 300,000 cycles. It is suitable for power relays and temperature controllers.
This manual describes the Omron G6D series power relay, a compact, high‑density relay designed for PLC and temperature‑control applications. It includes mechanical dimensions, contact materials, and environmental limits.
Key sections cover electrical characteristics such as coil voltage and contact ratings, mechanical performance like life expectancy and vibration resistance, as well as installation instructions, wiring diagrams, and certification information (UL, CSA, EN/IEC). This manual is written in Chinese.
| Contact rating (AC) | 5 A at 250 V AC |
|---|---|
| Contact rating (DC) | 5 A at 30 V DC |
| Mechanical life | ≥300 000 cycles |
| Insulation resistance | ≥1 MΩ |
| Contact resistance | ≤100 mΩ |
| Operating time | ≤10 ms |
It can handle 5 A at 250 V AC and 5 A at 30 V DC.
The relay is specified for at least 300 000 make‑break cycles.
