ASRock 775i915P-SATA2 Motherboard User Manual
This guide introduces the ASRock 775i915P‑SATA2 motherboard, an ATX‑form‑factor board with an Intel 915P northbridge and ICH6 southbridge. It lists package contents, connector locations, and key specifications such as CPU socket type, memory support and expansion slots.
The document provides detailed installation procedures, safety precautions, BIOS access instructions and a list of supported PCI‑Express graphics cards. It also includes information on SATA/SATA‑II connectors, power connectors, and software support on the accompanying support CD.
| Form Factor | ATX (12.0‑in x 9.6‑in) |
|---|---|
| CPU Socket | 775‑Pin LGA (Intel® Pentium® 4 / Celeron® D) |
| Chipset | Northbridge Intel 915P, Southbridge Intel ICH6 |
| Memory Support | 2 × DDR DIMM (DDR400/333, max 2 GB) + 4 × DDRII DIMM (DDRII533, max 4 GB) |
It supports Intel® Pentium® 4 and Celeron® D processors in the 775‑Pin LGA package.
