ASRock 775XFire-RAID Motherboard User Manual
This guide introduces the ASRock 775XFire-RAID motherboard, showing the board layout, connector locations, and key specifications such as CPU socket, memory slots, and expansion slots. It also lists the package contents and provides a quick reference to supported CPUs, chipsets, and RAID capabilities.
The document includes safety precautions, detailed CPU and component installation steps, BIOS access instructions, and information on configuring RAID, audio, and networking. It directs users to the support CD and ASRock website for the full user manual and driver updates.
| Form Factor | ATX (12.0‑in x 8.6‑in, 30.5 cm x 21.8 cm) |
|---|---|
| CPU Socket | LGA 775 |
| Supported CPUs | Intel Pentium 4 / Celeron D |
| Chipset | Northbridge Intel 925X, Southbridge Intel ICH6R |
| Memory | 4 × DDRII DIMM slots, DDRII‑533, max 4 GB |
| Audio Codec | Realtek ALC861 7.1‑channel |
| LAN | Realtek PCI LAN 8101L, 10/100 Mbps |
| SATA Connectors | 4 × 1.5 Gb/s SATA (RAID support) |
The board provides four ready‑to‑use USB 2.0 ports on the rear panel and two internal USB 2.0 headers that support four additional ports.
It supports RAID 0, RAID 1, and Intel Matrix Storage.
