WV-CP250 series camera has color to black and white function, which can automatically switch to color mode or black and white mode in the day and night, truly realizing 24 hours monitoring. With the optional F0.95 lens, the clear images can be captured respectively at the illumination as low as 0.5Lux (color mode) and 0.07Lux (black and white mode). In addition, it also includes a series of other features, such as 480 horizontal lines in color mode, 570 horizontal lines in black and white mode; 50dB signal-to-noise ratio; backlight compensation (BLC); aperture correction; automatic gain control (AGC) and automatic tracking white balance (ATW) functions.
The WV-CP250 series camcorder offers automatic day/night switching, allowing clear imaging in both color (480 lines) and black‑and‑white (570 lines) modes. It supports low illumination levels down to 0.5 Lux in color and 0.07 Lux in B/W with an F0.95 lens, making it suitable for 24‑hour monitoring in various environments.
Key specifications include a 1/3‑type CCD sensor, CS‑mount lens compatibility, multiple synchronization options, and a compact size of 70 × 65 × 127 mm (without lens). The unit operates from AC 220‑240 V (3.9 W) or 12 V (33 W) and functions in temperatures from –10 °C to +50 °C with humidity below 90 %. This manual is written in Chinese.
| Model | WV-CP250 |
|---|---|
| Image sensor | 1/3‑type CCD |
| Resolution | 752 × 582 pixels |
| Scanning range | 5.59 × 4.68 mm |
| Scan mode | 2.1‑field interlaced |
| Horizontal resolution (color) | 480 lines |
| Horizontal resolution (B/W) | 570 lines |
| Signal‑to‑noise ratio | 50 dB |
| Minimum illumination (F0.95 lens) | 0.5 Lux (color), 0.07 Lux (B/W) |
| Lens mount | CS mount |
| Dimensions (without lens) | 70 × 65 × 127 mm |
| Weight (approx., without lens) | 460 g |
| Operating temperature | -10 °C to +50 °C |
| Operating humidity | < 90 % |
Yes, it can automatically switch from color mode during the day to black‑and‑white mode at night, with a manual option available.
The minimum illumination is 0.5 Lux in color mode when using an F0.95 lens.
It provides a horizontal resolution of 570 lines in black‑and‑white mode.
The camcorder supports lenses with a CS mount.
