User manual of wireless surround sound system, introducing the installation, connection and usage of the product
This manual explains how to install and use the Philips RWSS5510 and RWSS9500 wireless rear audio system. It covers safety warnings, compliance information, and step‑by‑step instructions for placing the wireless receiver, connecting the transmitter and rear speakers, and powering the system.
Additional sections include troubleshooting tips for common issues such as no sound from the rear speakers, detailed product specifications for both models, and disposal guidelines for end‑of‑life handling.
| RWSS5510 Power supply rating | 110-240V, ~50-60 Hz |
|---|---|
| RWSS5510 Total output power | 250 W (RMS) |
| RWSS5510 Power consumption | 50 W |
| RWSS5510 Standby power consumption | 0.45 W |
| RWSS5510 Frequency response | 150 Hz ~ 20 kHz |
| RWSS5510 S/N Ratio | 65 dB (A‑Weighted) |
| RWSS5510 Distortion | 1% |
| RWSS5510 Dimensions (WxHxD) | 126 x 131 x 126 mm |
| RWSS5510 Weight | 11 kg |
| RWSS9500 Power supply rating | 110-240V, ~50-60 Hz |
| RWSS9500 Total output power | 300 W (RMS) |
| RWSS9500 Power consumption | 40 W |
| RWSS9500 Standby power consumption | 0.45 W |
| RWSS9500 Frequency response | 150 Hz ~ 20 kHz |
| RWSS9500 S/N Ratio | 65 dB (A‑Weighted) |
| RWSS9500 Distortion | 1% |
| RWSS9500 Dimensions (WxHxD) | 265 x 116 x 106 mm |
| RWSS9500 Weight | 1.4 kg |
| Wireless transmitter Frequency response | 5.8 GHz |
| Wireless transmitter Dimensions (WxHxD) | 55 x 53 x 33 mm |
| Wireless transmitter Weight | 0.05 kg |
Place the wireless receiver near an AC outlet between the rear speakers, align it with the home theater so the Philips logo faces the theater, and connect the power cord.
Disconnect the power cord and speaker cables from the wireless receiver for about a minute, then reconnect them, turn the home theater off and on again, and ensure the receiver is set to the correct source.
Both the RWSS5510 and RWSS9500 models operate on a power supply rating of 110‑240 V, ~50‑60 Hz.
Do not expose the product to rain or water, keep it away from flames or heat sources, do not insert objects into ventilation slots, and always disconnect it from power before cleaning or during lightning storms.
