The DPT50 Series is a 50-watt embedded power supply with a wide input voltage range of 90-264 VAC and 127-300 VDC. It features fully regulated output and overload and short circuit protection. This power supply has an efficiency of 80% and a high MTBF.
The DPT50 Series embedded power supplies deliver 30‑50 W total power with a universal AC input range of 90‑264 VAC and optional DC input up to 300 VDC. Key features include CE Mark EMC & LVD compliance, fully regulated output, overload and short‑circuit protection, high efficiency, and a built‑in EMI filter.
The handbook lists detailed electrical specifications, safety certifications (UL, CSA, VDE, CE), environmental ratings, and ordering information for each model variant. Mechanical drawings, pin‑out arrangements, and contact details for global support are also included.
| Total Power | 30‑50 W |
|---|---|
| Input Voltage Range (AC) | 90‑264 VAC |
| Maximum Output Power | 50 W |
| Efficiency | 80 % at typical full load |
| Hold‑up Time | 10 ms at full load |
| MTBF | >550,000 hours |
The series accepts an AC input voltage from 90 VAC to 264 VAC (wide range) and a DC input from 127 VDC to 300 VDC.
The maximum output power is 50 W.
The demonstrated MTBF is greater than 550,000 hours at full load and 25 °C ambient.
