This manual introduces the FSG series vacuum air grippers, including product features, specifications, application scenarios, etc.
The FSG series suction cups are designed for crawling and vacuum handling applications. The guide provides technical data for each size variant, including external diameter ranges, thread dimensions and minimum curvature radius.
Key performance parameters such as operating temperature limits, material hardness and achievable vacuum degree are listed, together with contact information for Bosch Rexroth sales and service locations worldwide. This manual is written in Japanese.
| External diameter range | 5 mm – 10 mm (F=0.75‑4 Nr) |
|---|---|
| Operating temperature range | -109 °C to +705 °C (continuous) |
| Short‑term temperature range | -30 °C to +120 °C (≤30 s) |
| Material hardness | 55 Shore A (ISO 7619‑1:2010) |
| Abrasion resistance | 100‑120 mm³ (ISO 4649:2002) |
| Vacuum degree | 60 % (no safety factor) |
The FSG series can operate continuously from –109 °C up to +705 °C, with short‑term limits of –30 °C to +120 °C for periods under 30 seconds.
The material complies with ISO 7619‑1:2010 at 55 Shore A.
