This document is a service manual for a color television, providing instructions on servicing notices, including avoiding X-rays, using designated parts, and handling cathode-ray tubes.
This service manual provides safety instructions, general specifications, and detailed disassembly procedures for the Toshiba 27A41 color television. It includes guidance on handling high‑voltage components, X‑ray safety, and proper re‑assembly after service.
The document also lists replacement part numbers, ordering information, and accessory details such as remote control specifications and interface switches, helping technicians perform repairs and maintenance efficiently.
| CRT size | 27 inch / 676 mm |
|---|---|
| Color system | NTSC |
| Sound output (max) | 2542.5 W |
| Power consumption (operating) | 120 W at 120 V 60 Hz |
| Standby power | 4 W at 120 V |
| Net weight | 35 kg |
| Dimensions (W×D×H) | 650 mm × 500.5 mm × 560 mm |
Any part marked with an “A\” in the circuit diagram or parts list must be replaced with a designated part that has the same incombustibility and voltage‑withstand characteristics.
