The Video Splitter is an ATEN product that can copy any analog video source to two, four, or eight output devices, and is suitable for broadcasting video information to the public, monitoring harsh working environments from a safe location, classrooms or corporate training facilities.
The VS-82/VS-84/VS-88 series are video splitters that duplicate an analog video source to 2, 4, or 8 displays respectively, extending signal distance up to 65 m. They support VGA, SVGA and Multisync monitors and can be stacked in up to three levels for larger installations.
The manual covers FCC and RoHS compliance, package contents, detailed installation steps, stacking procedures, component descriptions, technical specifications, and warranty terms, helping users set up and maintain the devices safely and efficiently. This manual is written in Chinese.
| Maximum display connections | 2 (VS-82), 4 (VS-84), 8 (VS-88) |
|---|---|
| Video bandwidth | 250 MHz (VS-82), 200 MHz (VS-84) |
| Maximum power consumption | 1.35 W (VS-82), 2.25 W (VS-84), 2.5 W (VS-88) |
| Maximum transmission distance | 65 m (210 ') |
| Operating temperature range | 0 °C – 50 °C |
The VS-84 model supports up to four displays.
Use a UL2919‑rated high‑density HDB‑15 VGA cable.
Yes, up to three levels can be stacked, and different models (VS‑82, VS‑84, VS‑88) can be mixed in the same chain.
