The VE200 video signal extender can extend the connection distance between the computer system and the display screen. At a transmission distance of up to 200 meters, the video resolution can reach 1280 x 1024@60Hz. The near-end transmission device (VE200L) and the remote receiving device (VE200R) are connected via Cat 5e twisted pair cables to extend the signal transmission distance. The VE200 video signal extender can meet the requirements of management and security applications. When the display screen is placed in an open area convenient for video playback, it can ensure that the system equipment is placed in a secure and hidden area. Other environments suitable for the VE200 video signal extender include finance, education, and business.
The VE200 video signal extender allows video transmission over distances up to 200 meters while maintaining resolutions up to 1280 × 1024 @ 60 Hz. It uses standard Cat 5e twisted‑pair cabling and supports VGA, SVGA, XGA, SXGA, UXGA, and WUXGA formats.
The manual describes connector types (HDB‑15, Mini‑Stereo Jack, RS‑232), power requirements (3.9 W), and environmental limits (operating temperature –20 °C to 60 °C, humidity 0 %–80 % RH). Installation guidelines and safety considerations for various environments such as finance, education, and commercial settings are also included. This manual is written in Chinese.
| Maximum transmission distance | 200 m |
|---|---|
| Maximum resolution at 200 m | 1280 × 1024 @ 60 Hz |
| Cable type | Cat 5e twisted‑pair |
| Operating temperature range | -20 °C to 60 °C |
The VE200 can transmit video at up to 1280 × 1024 @ 60 Hz over 200 m.
The extender uses standard Cat 5e twisted‑pair cable.
It can transmit video up to a distance of 200 meters.
