TC74HC597AP/AF is a high-speed CMOS 8-bit shift register with low power consumption, high speed, high noise margin, high fan-out, symmetrical output impedance, balanced delay time, wide operating voltage range, etc.
The TC74HC597AP/AF is an 8‑bit shift register/latch with parallel‑load capability, using Toshiba's high‑speed OMOS CMOS technology. It features low power consumption, diode input protection, and is pin‑compatible with the 74LS597.
The document provides absolute maximum ratings, operating conditions, DC and AC characteristics, timing diagrams, package dimensions, and handling instructions for the device. This manual is written in Japanese.
