This is a maintenance manual that introduces the use and maintenance methods of the DVI DL 201 Tx/Rx model.
The DVI DL 201 Tx/Rx is a dual‑link DVI transmitter and receiver that extends video signals over twisted‑pair cable. It supports resolutions up to 2560 × 1600 @ 60 Hz and cable runs up to 100 ft (30 m). The manual covers safety warnings, power handling, and proper mounting options.
The guide includes detailed installation procedures, EDID management, DDC switch configuration, pass‑through modes, and a troubleshooting section. Appendices list specifications, included parts, optional accessories, and warranty information.
| Maximum cable length | 100 ft (30 m) |
|---|---|
| Maximum resolution | 2560 × 1600 @ 60 Hz |
| FCC classification | Class A |
Press and release the EDID “Store” button; the LED turns amber while reading and then green when stored.
The product is warranted for three years from the date of purchase.
