This document provides information on the precautions, safety instructions, and operating guidelines for the High Resolution Video and Serial Link Mini Twisted Pair Transmitter Assembly by Extron Electronics.
The MTP 4T 15HD RS is a four‑channel twisted‑pair transmitter that distributes high‑resolution video and RS‑232 serial data over CAT5e/6 cable. It works with Extron's Enhanced Skew‑Free™ A/V UTP cable and can be paired with compatible MIP receivers for daisy‑chained video distribution.
The manual covers safety symbols, power requirements, installation (including rack mounting and tabletop placement), front‑panel controls, skew‑delay compensation, cable advantages, transmission distance tables, part numbers, and warranty information.
| Number of Transmitters | 4 transmitters in a single enclosure |
|---|---|
| Maximum Receivers per Transmitter | Up to 8 receivers daisy‑chained |
| Warranty | 3 years parts and labor |
Up to eight receivers can be daisy‑chained to a single transmitter.
