This document introduces the specifications and technical data of the 4SHH-250E scroll semi-hermetic piston compressor from Emerson, including power, dimensions, weight, and connection size. This product is suitable for refrigeration applications and is characterized by high cooling efficiency and reliability.
This guide provides technical data for the Emerson 4SHH-250E semi‑hermetic reciprocating compressor, such as dimensions, weight, power ratings and performance parameters. It also lists the standard pipe sizes, mounting dimensions and optional accessories.
The document includes a wiring diagram for the motor and control components, as well as detailed compressor configuration options like inlet/outlet thread specifications, oil filter, and crankcase heater details. An application guideline points to the related usage manual for further installation instructions. This manual is written in Chinese.
| Length | 670 mm |
|---|---|
| Width | 490 mm |
| Height (without fan) | 495 mm |
| Net Weight | 194 kg |
| Gross Weight | 221 kg |
| Suction Port Size | 1/8 inch |
| Discharge Port Size | 1/8 inch |
Both the suction port and the discharge port are 1/8 inch in size.
The compressor measures 670 mm in length, 490 mm in width, and 495 mm in height without the fan.
The net weight is 194 kg.
Yes, it provides a wiring diagram showing motor connections, contactors and control modules.
