This document is about the specification of EMERSON 2SCW-055E 谷轮半封闭活塞压缩机, including the product's technical parameters, performance parameters, nomenclature, compressor nameplate example, compressor configuration, compressor wiring diagram, electrical code description, and optional accessories.
This guide provides the technical specifications and performance data for the Emerson 2SCW-055E semi‑hermetic reciprocating compressor. It includes nominal power, cylinder count, bore‑stroke dimensions, displacement, weight, oil capacity and operating pressure ranges.
The document also contains a wiring diagram, standard and optional configuration options, dimension drawings, and contact information for Emerson regional offices. It references related product manuals for further installation and service details. This manual is written in Chinese.
| Nominal Power (HP) | 55 |
|---|---|
| Bore x Stroke (mm) | 60.3 x 54 |
| Displacement (m³) | 26.8 |
| Oil Charging (L) | 2.4 |
| Gross Weight (kg) | 96 |
| Dimension Width (mm) | 330 |
| Height (mm, no fan) | 395 |
The nominal power is 55 HP.
The oil charging capacity is 2.4 L.
