The document describes the features and benefits of Jameco MX07 E-97 E Power Connectors 3.00mm (.118") Pitch Micro-Fit 3.0™ Wire-to-Board Header 43045 Dual Row Vertical F, including optimum retention to PC board during wave soldering, fully polarized to mating receptacle, peg feature provides polarization to PCB, surface mount compatible, etc.
The Molex 43045 is a 3.00 mm (0.118 in) pitch Micro‑Fit 3.0 wire‑to‑board header offered in a dual‑row vertical configuration. It features a solderable retention clip, full polarization, and is available with tin or gold plating.
The datasheet provides electrical ratings, mechanical requirements, environmental limits, and packaging details, including UL and CSA approvals. It is intended for designers and manufacturers needing precise connector specifications.
| Pitch | 3.00 mm (0.118 in) |
|---|---|
| Voltage rating | 250 V |
| Maximum current | 5.0 A |
| Contact resistance | 10 mΩ max. |
| Dielectric Withstanding Voltage | 1500 V AC |
| Insulation resistance | 1000 MΩ min. |
| Insertion force to PCB | 7.5 kgf max. (16.5 lb) |
| Housing material | High temperature LCP (UL 94‑V0) |
| Contact material | Brass |
| Plating | Tin or Gold |
| Operating temperature range | -40 °C to +105 °C |
| UL file number | E29179 |
| CSA file number | LR19980 |
The header is rated for 250 V.
It can carry up to 5.0 A maximum.
It withstands 1500 V AC.
The required insertion force is up to 7.5 kgf (16.5 lb).
