Features Power dissipation : 0.35W
This document is a datasheet for the Comchip 2N7002-HF, an N-Channel MOSFET designed as a RoHS and Halogen Free device. It provides comprehensive electrical characteristics including drain-source breakdown voltage, gate threshold voltage, and various capacitance values measured at 25°C.
The datasheet also includes mechanical specifications for the SOT-23 package, offering dimensions in both inches and millimeters, reel taping specifications, and suggested pad layouts for PCB design. Additionally, it lists standard packaging quantities and marking codes.
| Power dissipation | 0.35W |
|---|---|
| Drain-Source voltage | 60 V |
| Drain current | 250 mA |
| Junction and storage temperature | -55 ~ +150 °C |
The device has a maximum power dissipation of 350 mW.
The junction and storage temperature range from -55 to +150 °C.
A standard reel contains 3000 pieces of the device.
