Transcend TS0/128/256MFLRD7 USB 2.0 Multi-Card Reader User Manual
The TS0/128/256MFLRD7 is a USB 2.0 multi‑card reader that supports CompactFlash, Microdrive, SmartMedia, Secure Digital, miniSD (with adapter), MultiMediaCard, RS‑MMC (with adapter), Memory Stick variants, and optional built‑in flash (0 MB, 128 MB or 256 MB). It complies with USB 2.0 standards, is plug‑and‑play, and requires no external power.
This manual covers system requirements, driver installation (when needed), step‑by‑step usage on Windows 98/2000/Me/XP, Mac OS 9/OS X, and Linux, safe removal procedures, LED indicator meanings, product specifications, ordering information, and warranty terms. This manual is written in Chinese.
Transcend TS0 specifications
| Dimensions | 85 mm × 49 mm × 15 mm (L × W × H) |
|---|---|
| Upstream Port | 1 × mini‑B (Series‑mini‑B) |
| Downstream Ports | 4 × Series‑A |
| Power Supply | DC 5 V 2.3 A |
| Typical Power Consumption | 300 mA |
| Over‑current Protection | 1250 mA |
| Maximum Output Current | 500 mA |
| Operating Temperature | 0 °C – 80 °C |
| Operating Humidity | 0 % – 40 % RH |
| Certifications | FCC, CE, UL, TUV, TSE |
All Transcend TS0 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I install the Transcend TS0MHUB4 hub?
Connect the supplied power adapter to the hub’s power socket, plug the power adapter into an outlet, then connect the hub’s mini‑B upstream port to the computer and attach devices to the four downstream ports.
What power specifications does the hub require?
It uses a DC 5 V, 2.3 A power supply, draws about 300 mA in normal operation, and includes over‑current protection up to 1250 mA.
