STMICROELECTRONICS ULQ200XA/XD1 handbook

Datasheet

ULQ200XA/XD1 is a high voltage, high current darlington array from STMicroelectronics. It has seven open collector darlington pairs with common emitters, each channel rated at 500mA and can withstand peak currents of 600mA. It can be used for a wide range of applications including driving solenoids, relays, DC motors, LED displays, filament lamps, thermal print-heads and high power buffers.

ST ULN200XA/XD1 Manual

User Manual

The ULN2001, ULN2002, ULN2003 and ULN2004 are high voltage, high current darlington arrays each containing seven open collector darlington pairs with common emitters. Each channel rated at 500mA and can withstand peak currents of 600mA. Suppression diodes are included for inductive load driving and the inputs are pinned opposite the outputs to simplify board layout.
