STMicroelectronics ULN200xA / ULN200xD1 Datasheet
The ULN200xA and ULN200xD1 families are high‑voltage, high‑current Darlington arrays containing seven open‑collector drivers with common emitters. They are suitable for driving loads such as solenoids, relays, DC motors, LED displays, filament lamps, thermal printheads and power buffers, and are compatible with TTL, CMOS, PMOS and DTL logic families.
Key features include a maximum output current of 500 mA per driver (600 mA peak), 50 V output voltage rating, integrated suppression diodes for inductive loads, and availability in 16‑pin DIP and narrow‑body SO packages. The datasheet details absolute maximum ratings, electrical characteristics, pin assignments, and test circuits for design reference.
STMicroelectronics ULN200XA specifications
| Output current per driver | 500 mA (600 mA peak) |
|---|---|
| Output voltage rating | 50 V |
| Input voltage (ULN2002A/D etc.) | 30 V |
| Continuous collector current | 500 mA |
| Continuous base current | 25 mA |
| Operating ambient temperature range | -20 °C to 85 °C |
| Thermal resistance (junction‑ambient) DIP‑16 | 70 °C/W |
| Thermal resistance (junction‑ambient) SO‑16 | 120 °C/W |
All STMicroelectronics ULN200XA documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the maximum output current per driver?
Each driver can source up to 500 mA continuously, with a peak capability of 600 mA.
Which packages are available for the ULN200xA series?
The devices are offered in a 16‑pin DIP package and a narrow‑body 16‑pin SO (surface‑mount) package.
What is the maximum continuous collector current per driver?
Each driver can handle a continuous collector current of 500 mA.
What is the maximum output voltage rating?
The devices are rated for a maximum output voltage of 50 V.
What is the maximum output voltage of the ULN200XA/XD1?
The device can handle an output voltage of up to 50 V.
How many darlington channels does the ULN200XA/XD1 provide?
It contains seven darlington channels.
