Start here
Futaba 6EXAP Instruction Manual
This document is the instruction manual for the Futaba 6EXAP, a 6-channel digital proportional R/C aircraft system. It serves as a guide for users setting up and operating the transmitter and receiver components for sport and recreational flying of radio-control models.
The manual details the introduction to the system, descriptions of transmitter controls including dual rate switches and trim levers, and instructions for installing the receiver and connecting servos. It also covers programming functions such as servo reversing, end point adjustments, mixing, and fail-safe settings.
Futaba 6EXA specifications
| Transmitter model | T6EXA |
|---|---|
| Transmitter power supply | 9.6 V, 600 mAh Ni‑Cd battery |
| Receiver model | R127DF narrow‑band FM 7‑channel |
| Receiver power requirement | 4.8 V or 6 V Ni‑Cd battery |
| Number of model memories | 6 |
All Futaba 6EXA documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many model memories can the Futaba 6EXA store?
The transmitter can store model memories for six different models.
What is the correct order to turn off the system?
Turn off the receiver first, then the transmitter.
What modulation types does the Futaba 6EXAP support?
The system transmits in both FM (PPM) and PCM by selecting modulation.
What is the purpose of the dual rate switch?
It allows the user to instantly switch between two different control throws for aileron, elevator, and rudder.
