Key facts
- Brand
- Futaba
- Model
- 2PL
- Category
- Other Electronics
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-08-09
Start here
Futaba 2PL-2.4G Instruction Manual
The document serves as an instruction manual for the Futaba FHSS 2PL 2.4GHz digital proportional R/C system, designed specifically for controlling car models. It details the system's features, including its 2.4GHz Spread Spectrum (FHSS) technology which automatically sifts channels to minimize interference and uses ID codes to reject unwanted signals.
The guide covers essential safety precautions regarding battery usage, moisture protection, and operating visibility. It provides step-by-step procedures for assembling the system, connecting receivers and servos, linking the transmitter and receiver, and performing initial setup adjustments such as steering trim, throttle trim, dual rates, end point adjustment, and fail-safe functions.
All Futaba 2PL documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the primary use of this system?
This product may be used for models only. It is not intended for use in any application other than the control of models for hobby and recreational purposes.
How does this system handle frequency channels?
The system minimizes interference from other 2.4GHz systems by automatically sifting the channels within the 2.4GHz band, making manual channel setting unnecessary.
What is the maximum recommended distance for performing a range test before operating the model?
You should operate the transmitter from a distance of about 100 feet while the antenna is collapsed.
From: Futaba 2PL Digital Proportional R/C System Instruction Manual
What specific condition must be met regarding the transmitter antenna before operating the model?
The transmitter antenna must be fully extended to prevent range reduction and potential loss of control.
From: Futaba 2PL Digital Proportional R/C System Instruction Manual
