Fluke F190 Series ScopeMeter User Manual
The F190 series ScopeMeter features fully isolated dual‑channel inputs, allowing safe simultaneous measurement of high‑voltage and low‑voltage signals. Its isolation safety level reaches Class II 1000 V and Class III 600 V, making it suitable for industrial environments where large voltage differences are common.
The instrument’s 2.5 GSa/s sampling rate and automatic trigger functions enable accurate analysis of motor drives, PWM inverters, and switching power supplies. With a current clamp accessory it can also measure active, reactive, and apparent power as well as power factor, supporting comprehensive diagnostics of power‑factor and system‑wide power distribution. This manual is written in Chinese.
All Fluke F190 documents by type
How to use the product for one specific task, with worked examples.
Questions answered in these manuals
What sampling rate does the F190 provide?
It offers a sampling rate of up to 2.5 GSa/s.
Can the F190 be used to measure power factor in industrial systems?
Yes, using a current clamp it can measure active, reactive, apparent power and directly calculate power factor.
What is the maximum sampling rate of the 190 Series ScopeMeter?
The instrument can sample at up to 2.5 GSa/s.
