Comprehensive product catalog for Vacon variable frequency drives including selection guides, series descriptions, technical parameters, and application areas.
This document serves as a comprehensive assembly of Vacon variable frequency drive products. It provides a concise selection guide to help users choose the correct power rating based on load conditions (pumps, fans) and environmental temperature.
The catalog details various product series including the NX family (NXL compact/universal, NXS industrial, NXP high-performance engineering/water-cooled, NXC cabinet), Standalone light-duty cabinets, common DC bus products, and legacy 10/100/X series. It covers power ranges from 0.25kW to 5MW and addresses control methods such as U/f control, sensorless vector control, and closed-loop vector control. This manual is written in Chinese.
| Power Range | 0.25kW to 5MW |
|---|---|
| Operating Temperature (Standard) | 40°C, 45°C, 50°C |
| Max Operating Temp (High Power NXP/NXC) | 35°C |
The two decisive factors are load conditions (pump, fan or other loads) and ambient temperature.
Vacon drives cover a power range from 0.25kW to 5MW.
Using a water-cooled Vacon NXP can save up to 70% of the space required for an air-cooled model.
For these specific high-power models, the maximum operating temperature is 35°C.
