This manual introduces the basic overview, installation, connection, operation and parameter setting of vacon 5x drives.
This manual covers the Vacon 50X alternating frequency transformer, describing its technical characteristics, rated voltage and current, power range, dimensions, and enclosure ratings. It includes detailed installation instructions, wiring diagrams for the control board, and configuration of digital and analog inputs.
The document also explains operation modes, parameter settings, fault diagnosis, and PI control principles, and provides contact information for Vacon support in China and worldwide. This manual is written in Chinese.
| Rated current | 23 A |
|---|---|
| Dimensions | 165 × 241 × 155 mm |
| Enclosure rating | NEMA 4X / IP66 and NEMA 12 / IP55 |
| Input type | Three‑phase |
The Vacon 50X is available with NEMA 4X / IP66 and NEMA 12 / IP55 enclosure ratings.
Section 4 of the manual describes the terminals on the Vacon 50X control board, including digital inputs, analog outputs, and power contacts.
Fault diagnosis procedures are provided in section 8, titled "Vacon 50X故障代窟".
