Vacon 500X Alternating Frequency Transformer User Manual

This document lists the summary of VACON 500X parameters.

Brand: Vacon
Document type: User Manual
Language: English
Pages: 124
File format: PDF
File size: 1.1 MB
Published: 31 March, 2012
Updated: 30 September, 2023
MD5 checksum: BF637B06F7FA61B0B9B48BBA0FD33F77
PDF: Vacon 500X Alternating Frequency Transformer User Manual PDF

About this manual

This manual lists all configurable parameters for the Vacon 500X drive, including rated current, output frequency, voltage settings, communication options, and advanced features such as PID control and ramp profiles. The tables give default values, allowed ranges, and read‑only status for each parameter.

Contact information for Vacon worldwide offices and technical support is included, along with phone numbers, fax numbers, and email addresses for service and sales inquiries.

What's inside

Parameter Overview
Frequency and Voltage Settings
Communication and Bus Options
Ramp, Acceleration and Deceleration
PID Control Settings
Display Language and Units
Fault and Diagnostic Information
Technical Support Contacts

Specifications

Rated Current	0.0‑200.0 A
Output Frequency	0.0‑400.0 Hz
Output Voltage	0‑600 V
DC Bus Voltage	0‑1000 V AC
PWM Frequency	0.6‑16.0 kHz (default 3.0 kHz)
Display Language	English

Frequently asked questions

What is the rated current range for the Vacon 500X?

The rated current can be set between 0.0 A and 200.0 A.

What output frequency range can be configured?

The output frequency is adjustable from 0.0 Hz up to 400.0 Hz.

How do I change the display language?

Set the Language parameter to the text string "English".

What is the default PWM frequency and its allowed range?

The default PWM frequency is 3.0 kHz, with an allowable range of 0.6 kHz to 16.0 kHz.
