Vacon AC drives are the best choice for new elevator design and renovation projects, and can save energy, save costs, and significantly shorten the equipment debugging cycle. Vacon variable frequency drive has the characteristics of precise and smooth control, low noise, compact structure and modular design, which can meet the application needs of various environments in the elevator industry.
This guide introduces Vacon's AC drives for elevators, highlighting benefits such as energy savings, compact design, modular construction, and quiet operation. It explains how the drives improve comfort, reduce noise, and shorten commissioning time for new or retrofit projects.
The document provides detailed technical specifications, safety and EMC standards, optional encoder cards, and PC tools for configuration and diagnostics. It also lists optional accessories, dimensions, weight, and contact information for Vacon partners. This manual is written in Chinese.
| Power range | 3–18.5 kW |
|---|---|
| Input voltage | 208–240 V; 380–500 V ±10 % |
| Chopping frequency | 1–16 kHz |
| Operating temperature range | -10 °C … +40 °C |
| Protection functions | over‑voltage, under‑voltage, ground fault, main‑circuit monitoring, over‑current, over‑temperature, motor overload, motor stall, motor underload, +24 V/+10 V reference short‑circuit |
The drives accept 208–240 V or 380–500 V input voltage, with a tolerance of ±10 %.
Incremental encoder cards (OPT‑A4/A5) for closed‑loop control and absolute encoder cards (OPT‑BE/AK) for permanent‑magnet motor control are available.
The Vacon NXP drive operates at a chopping frequency of 8 kHz at 50 % ED.
