This is a manual for vacon frequency converter. It mainly introduces the product's technical characteristics, power and current ratings, environmental instructions, electrical instructions, control characteristics instructions, dimensions and weights.
This manual describes the Vacon 50X AC variable frequency drive, a compact industrial drive with remote communication, panel configuration, and NEMA/IP rated enclosures. It includes an introduction, technical specifications, receiving and installation guidelines, wiring diagrams, panel operation, programming, macro mode, and maintenance procedures.
The document also covers detailed parameter tables for different voltage ranges, environmental limits, control features, PI control theory, and EU compliance. Troubleshooting, quick‑start steps, and macro‑mode programming are explained with reference to the on‑panel menus and Modbus communication. This manual is written in Chinese.
| Input Voltage | 230 V |
|---|---|
| Input Voltage | 380‑480 V |
| Input Voltage | 575 V |
| Dimensions (W×H×D) | 165×241×155 mm |
The drive is available in NEMA 4X/IP66 and NEMA 12/IP55 rated enclosures.
