This manual covers installation, technical data, commissioning, and maintenance for the Vacon 20 X AC Drive with D-option.
This document serves as the installation, technical, and maintenance manual for the Vacon 20 X AC Drive equipped with the D-option. It provides comprehensive safety information, including warning signs and earthing requirements, as well as instructions for unpacking, lifting, and mounting the unit. The guide details power cabling procedures for various communication options such as AS-i, Profibus, CanOpen, and Devicenet, along with recommended plug terminals and cable dimensions.
The manual further outlines commissioning procedures, including motor insulation checks and running the motor. It includes specific sections on Safe Torque Off (STO) principles and connections, ensuring compliance with safety standards like Cat.1 / PL c / SIL 1. Additionally, it covers technical data regarding power ratings and overloadability, alongside maintenance guidelines and fault tracing parameters.
| Touch current | exceeds 3.5mA AC |
|---|---|
| Intended installation | fixed installations only |
| Motor types | asynchronous AC motors and permanent magnet motors |
Only Vacon authorized, trained and qualified personnel are allowed to install, operate and maintain the drive.
The cross-sectional area shall be not less than 4 mm² if mechanical protection is not provided.
The STO connections support Safety Capability Cat.1 / PL c / SIL 1.
