DRV8802-Q1 Dual H-Bridge Motor Driver IC Data Sheet

This datasheet details the DRV8802-Q1, a dual H-bridge motor driver IC for automotive applications featuring 1.6A peak current and 24V operation.

Brand: Texas Instruments
Category: Motor
Document type: Datasheet
Language: English
Pages: 28
File format: PDF
File size: 1.6 MB
Published: 18 October, 2026
Updated: 18 October, 2026
MD5 checksum: C575A40CC1C6B22D4E42A4412E4EC294
PDF: DRV8802-Q1 Dual H-Bridge Motor Driver IC Data Sheet PDF

About this manual

The DRV8802-Q1 is a dual H-bridge motor driver integrated circuit designed specifically for automotive applications. It features two H-bridge output drivers, each capable of driving a DC motor with a peak current of 1.6A. The device includes a parallel digital control interface compatible with industry-standard devices, allowing for control of two DC motors with adjustable decay modes for braking or coasting.

What's inside

Features
Applications
Pin Configuration and Functions
Specifications
Absolute Maximum Ratings
Recommended Operating Conditions
Thermal Information
Electrical Characteristics
Typical Characteristics
Detailed Description

Specifications

Internal PWM frequency	50 kHz
Package type	28-pin HTSSOP

Frequently asked questions

What is the maximum continuous motor drive current for the DRV8802-Q1?

The device supports a continuous motor drive current of 1.6 A.

What is the operating supply voltage range for the device?

The device operates with a supply voltage between 8 V and 45 V.

What is the maximum operating ambient temperature?

The device can operate in an ambient temperature range up to 125°C.

Download PDF (1.6 MB)
