Technical specifications and packaging details for the SunLED SUR92D 3.6mm side‑look LED lamp.
The SunLED SUR92D 3.6mm side‑look lamp is a radial/through‑hole LED offering low power consumption and RoHS compliance. It is supplied on tape and reel and is suitable for applications requiring reliable, robust illumination.
The datasheet provides absolute maximum ratings, electrical parameters, optical characteristics, and sorting accuracy for special requirements, as well as packaging and label specifications.
| Forward Voltage (Typ.) | 2 V |
|---|---|
| Forward Voltage (Max.) | 2.5 V |
| Reverse Current (Max.) | 10 µA |
| Peak Emission Wavelength (Typ.) | 627 nm |
| Dominant Emission Wavelength (Typ.) | 625 nm |
| Spectral Line FWHM (Typ.) | 45 nm |
| Operating Temperature | -40 °C to +85 °C |
| Power Dissipation | 75 mW |
| Forward Current (IF) | 30 mA |
The typical forward voltage is 2 V at a forward current of 20 mA.
The wavelength sorting accuracy is ±1 nm.
The maximum reverse current is 10 µA.
The lamp operates from –40 °C to +85 °C.
