The ROHM TCFG Series chip tantalum capacitor data sheet provides specifications, dimensions, ratings, and packaging details.
The TCFG series chip tantalum capacitors feature a fail‑safe open structure, a wide capacitance range, and screening by thermal shock. The document lists dimensions, part numbers, and marking conventions for the C‑case devices.
Technical data include rated voltage, capacitance tolerance, operating temperature limits, leakage current, and packaging specifications. Test conditions follow JIS C5101 standards, and the sheet also provides guidance on solderability, moisture resistance, and temperature stability for reliable use in electronic equipment.
| Leakage Current | 0.5 µA or 0.01 CV |
|---|---|
| Capacitance Range | 0.4 µF to 220 µF |
It includes a fail‑safe open structure built‑in.
