Technical handbook for Parker 3400-CN hose fittings, covering specifications, pressure ratings, material compatibility, and installation guidelines.
This document serves as a technical reference for the Parker 3400-CN series of hose fittings. It provides detailed information on product specifications, including various fitting end connections such as BSP, NPTF, SAE (JIC), and pipe swivel types.
The handbook includes critical data on maximum working pressure ratings with a safety factor of 4:1 for different tube sizes and connection styles. Additionally, it details material compatibility charts for fluids like hydraulic oils, fuels, and chemicals, as well as specifications for Parkrimp No-Skive crimping tools.
| Safety Factor | 4:1 |
|---|---|
| BSP Swivel Female Pressure (Metric) | 63.0 MPa |
The maximum working pressure ratings are based on a safety factor of 4:1.
The Parkrimp No-Skive fitting end connector is used, with specific tolerances defined in DIN 20066 and EN 853.
