Technical handbook for Parker industrial tube fittings covering selection, performance data, dimensions, assembly, troubleshooting and tooling.
The Parker 4100-10/UK Technical Handbook provides a comprehensive reference for the full range of industrial tube fittings offered by Parker. It includes guidance on systematic fitting selection, performance data, dimensioning, assembly procedures, troubleshooting tips and tooling information.
The catalogue is organized by fitting families such as DIN, ORLOK®, Triple‑Lok®, Ferulook®, weld fittings and high‑pressure hydraulic flanges. Detailed product pages describe specifications, pressure ratings and installation features, and an alphanumerical index at the end allows quick lookup of part numbers.
| External diameter range (Parflange F37) | 16 mm – 165 mm |
|---|---|
| Maximum wall thickness (Parflange F37) | up to 9 mm |
| Maximum pressure (Parflange F37) | up to 420 bar |
| Pressure rating (EO‑2 sealing ring) | 800 bar (S Series), 500 bar (L Series) |
| Pressure rating (37° flare system) | up to 600 bar (small sizes), up to 140 bar (large sizes) |
The Parflange F37 fitting is rated for pressures up to 420 bar.
It can be used with tubes that have an external diameter from 16 mm to 165 mm and a wall thickness up to 9 mm.
The EO‑2 fitting can handle 800 bar in the S Series and 500 bar in the L Series.
It is rated up to 600 bar for smaller sizes and up to 140 bar for larger dimensions.
