The Eurotherm Drives Catalogue introduces the features and characteristics of AC, DC, and Brushless Servo Drives. New products include easy-to-use AC inverters, ultra-high-performance brushless servo drives, standard and vector-controlled AC motors, and customizable cabinet-mounted AC and DC drives.
This catalogue presents Eurotherm's range of variable‑speed motor‑control products, including AC inverters, sensorless vector drives, closed‑loop vector drives, DC drives and servo drives. Each series is described with power ratings, input requirements, environmental ratings and optional features such as function‑block programming and fieldbus interfaces.
The document also provides technical specifications, standard compliance information, dimensions of cabinet‑mounted units and contact details for Eurotherm worldwide sales offices. Application guides and ancillary product listings are included to help users select the right drive for their industrial automation needs. This manual is written in Chinese.
| Power Supply (single phase) | 220‑240Vac ±10%, 50‑60Hz ±5% |
|---|---|
| Power Supply (three phase) | 380‑460Vac ±10%, 500V option available |
| Output Frequency | 0‑240Hz |
The 650 series is rated for 150% overload for 30 seconds.
The 690+ series covers power ratings from 0.75 kW up to 355 kW.
