Parker IM20 Series Servo Drive User Manual

About this manual

This manual provides detailed instructions for installing, wiring, and commissioning Parker IM20 series servo drives used in injection‑molding machines. It includes safety guidelines, technical specifications, and step‑by‑step procedures for setup and adjustment.

Additional sections cover fault analysis, routine inspection, and a communication handbook with command codes for remote control and diagnostics. This manual is written in Chinese.

What's inside

• Foreword
• Usage Instructions
• Technical Specifications and Selection
• Product Installation
• Electrical Connections
• Operation Panel and Function Parameters
• Injection‑Molding Machine System Debugging
• Fault Analysis and Troubleshooting
• Routine Inspection and Maintenance
• Appendices

Specifications

Frequently asked questions

What safety precaution must be observed when mounting the servo drive?

The servo drive must be installed vertically to ensure proper heat dissipation.

How can a fault be reset via the communication interface?

Send the command code 0x0009 to perform a fault reset.
