Infineon SmartLEWIS TM RX+ TDA5240/35/25 Explorer User Manual

About this manual

The SmartLEWIS TM RX+ Explorer is a Windows‑based tool for configuring the Infineon TDA5240, TDA5235, or TDA5225 RF receiver chips. It provides a wizard, register grid, logging, and a browser interface to generate and manage register settings.

The manual covers hardware and software requirements, installation steps, the user interface, detailed description of each configuration page, logging functions, and appendices with register patch lists and the SPI configuration file format.

What's inside

• Introduction
• Hardware and Software Components
• Software Installation
• User Interface and Getting Started
• TDA5240/35/25 Explorer Functions
• Logging
• Appendix – Register Patch List
• Appendix – SPI Configuration File Format

Specifications

Frequently asked questions

Which Windows versions can I run the SmartLEWIS TM RX+ Explorer on?

The software runs on Windows Vista, Windows 7 (32‑ or 64‑bit), Windows XP, and Windows 2000.

What screen resolution is required for the Explorer interface?

A minimum graphics resolution of 1024 × 768 is required.

Do I need any additional software to run the Explorer?

Yes, the Microsoft .NET Framework version 2.0 or higher must be installed.
