This document provides technical specifications, dimensions, and ordering information for the Eaton 32306 priority flow divider hydraulic valve.
The document details the Eaton 32306 priority flow divider, including its physical dimensions, port specifications, and available ordering codes with various control flow settings. It lists key technical specifications such as rated input flow, rated pressure, and maximum pressure drop. This manual is written in Chinese.
| Rated Input Flow | 96.6 L/min. [25 G.P.M.] |
|---|---|
| Rated Pressure | 172.4 bar [2500 PSI] |
| Maximum Pressure Drop | 4.5 bar [65 PSI] |
| Mass | 1.6 kg. [3.5 lbs.] |
The maximum rated input flow is 96.6 L/min. [25 G.P.M.]
The maximum pressure rating is 172.4 bar [2500 PSI].
The maximum pressure drop is 4.5 bar [65 PSI].
