The Eaton SM60 Supervisory Module User Manual provides control, monitoring and configuration instructions for the Powerware SM60 module.
The SM60 Supervisory Module is a cost‑effective control and monitoring solution for Eaton Powerware DC power systems. It features a simple menu‑driven interface, built‑in Ethernet, web server and SNMP communication options, and supports alarm configuration and system monitoring.
The module can be installed as a panel‑mount unit or mounted inside a rack door with an optional external LCD. It accommodates up to four shelves of APR or NPR hot‑swappable rectifier modules, enabling scalable power outputs of up to 378 kW at 48 V or 202 kW at 24 V.
| Mounting type | Panel mount, optional door‑mount with LCD |
|---|---|
| Maximum shelves supported | 4 |
| Communication interfaces | Ethernet, web server, SNMP |
| Maximum rack power (48 V) | 378 kW |
| Maximum rack power (24 V) | 202 kW |
The SM60 can accommodate up to four shelves of APR or NPR hot‑swappable rectifier modules.
It includes a built‑in Ethernet interface, a web server, and an SNMP agent for remote monitoring.
