Balluff BTL6-P111 Micropulse AT Displacement Sensor Datasheet

Technical datasheet for the Balluff BTL6-P111 Micropulse AT displacement sensor, covering installation, connection, and technical specifications.

Brand: Balluff
Category: Industrial Robot
Document type: Datasheet
Language: German
Pages: 40
File format: PDF
File size: 1009 KB
Published: 23 October, 2026
Updated: 23 October, 2026
MD5 checksum: ED376A80DBF102801D676200F57BCFD9
PDF: Balluff BTL6-P111 Micropulse AT Displacement Sensor Datasheet PDF

About this manual

This document is a technical datasheet and installation guide for the Balluff Micropulse AT displacement sensor (model BTL6-P111-M_ _ _ _-A1-S115). It describes the sensor's function, which uses a waveguide and a position sensor to measure linear displacement via torsional waves traveling at ultrasonic speed. The sensor is designed for use in machines or plants connected to a control unit (SPS) or evaluation unit. This manual is written in German.

What's inside

Sicherheitshinweise
Funktion und Eigenschaften
Einbau
Anschlüsse
Inbetriebnahme
Arbeiten mit dem DPI/IP-Verfahren
Technische Daten
Lieferumfang

Specifications

Power Supply	DC 24 V
Housing Diameter	30 mm
Cable Length	max. 500 m
Output Interface	RS 422
EMV Emission Standard	EN 55011 Group 1, Class B

Frequently asked questions

What is the recommended distance between the position sensor and magnetic materials?

The distance must be at least 10 mm.

What is the recommended distance between the position sensor and the waveguide?

A distance of 6 to 8 mm is recommended for optimal results.

What type of cable shielding is required for EMV compliance?

A copper wire braid with 80% coverage is required.
