ABB PS-M-64.1.1 Power Supply Technical Manual

About this manual

This manual covers safety guidelines, environmental requirements, and product description for the ABB free@home® PS-M-64.1.1 power supply. It includes technical data such as voltage ranges, current ratings, and protection class, as well as wiring diagrams and component dimensions.

Installation, debugging, and maintenance procedures are detailed, with instructions for proper mounting, connection, cleaning, and fault handling. Planning and application tips, including reset and LED status interpretation, are also provided.

What's inside

• Safety
• Environment
• Product Description
• Technical Data
• Installation
• Debugging
• Maintenance
• Planning and Application Tips

Specifications

Frequently asked questions

How should the device be installed?

It must be installed in a dry indoor enclosure, mounted on a 35 mm support rail.

What do the LED colors indicate?

Green shows normal operation, red indicates overload, and flashing red signals a short circuit.

How do I reset the power supply?

Disconnect the bus connection terminals for about 20 seconds, then reconnect to restart the bus line.
