ABB S200 series provides modular low‑voltage circuit breakers, RCDs and accessories for residential, commercial and industrial distribution.
The S200 series offers a complete range of terminal distribution protection devices, including miniature circuit breakers (MCB), residual‑current devices (RCD), surge protection components and DIN‑rail mounting accessories. All products comply with international standards and feature high breaking capacity, modular dimensions and easy installation.
The catalogue presents technical data, product families, mounting options and enclosure types, together with detailed specifications for each component, helping designers and installers select the right solution for their low‑voltage distribution needs. This manual is written in Chinese.
| 额定电压 | 230V/400V |
|---|---|
| 最大操作电压 | 690V |
| 热变形温度 | 113℃ |
| 绝缘强度 | 32 kV/mm |
| 最大分断能力 | 25 kA |
| 额定电流 | 100 A |
| 极数 | 1, 1+N, 2, 3, 3+N, 4 |
The S200 series breakers have a maximum breaking capacity of up to 25 kA.
They comply with IEC/EN 60898‑1, GB 10963.1, IEC/EN 60947‑2 and GB 14048.2 standards.
The rated voltage is 230 V/400 V.
