This is a product selection guide for Power Integrations' AC-DC product series. It introduces the features and characteristics of the products, including design simplification, EcoSmart® technology, technological innovation, product performance and advantages.
This service manual provides an overview of Power Integrations' AC‑DC product families such as LinkSwitch®, TinySwitch®, PeakSwitch® and TOPSwitch®. It includes part numbers, electrical ratings, and application references for each device.
The document also lists design‑support web sites, contact information for worldwide sales offices, and regulatory limits. It is intended for engineers and service technicians who need detailed product data and troubleshooting guidance.
| EP-85 Power Rating | 2 W |
|---|---|
| EP-54 Power Rating | 2.75 W |
| Input Voltage Range (LinkSwitch®‑TN) | 85‑265 VAC |
| Maximum Output Power (TOPSwitch‑HX) | 47 W |
Design‑support resources are listed at www.powerint.com/designsupport and on the various application pages linked in the manual.
The part number is EP‑34, rated 30 W at 12 V.
TOPSwitch‑HX belongs to the TOPSwitch product family of Power Integrations.
