This document describes the features and characteristics of AXIS 231D+/AXIS 232D+ network cameras, including support for both Motion JPEG and MPEG-4 dual streams, 18x optical zoom and 12x digital zoom lens, day/night functionality, and preset positions and auto patrol.
The Axis 231D+ and 232D+ are network PTZ cameras designed for professional surveillance. They feature 18× optical zoom, 12× digital zoom, day/night operation and low‑light performance down to 0.005 lux.
The manual covers technical specifications, installation steps, PTZ operation, video compression options (Motion JPEG and MPEG‑4), network security (HTTPS, IP filtering, IEEE 802.1X), alarm management and power requirements, along with software tools for configuration and firmware updates. This manual is written in Chinese.
| Optical Zoom | 18× |
|---|---|
| Digital Zoom | 12× |
| Minimum Illumination (Color) | 0.3 lux |
| Minimum Illumination (B&W) | 0.005 lux |
| Horizontal View Angle | 2.8° – 48° |
| Maximum Rotation Speed | 360°/s (horizontal & vertical) |
| Video Compression | Motion JPEG, MPEG‑4 Part 2 |
| Power Supply | 19‑28 VAC or 24‑40 VDC |
| Preset Positions | 100 |
The camera supports Motion JPEG and MPEG‑4 Part 2 compression.
The camera provides 100 preset positions.
Color video can be captured at a minimum illumination of 0.3 lux.
They operate from 19‑28 VAC (max 25 VA) or 24‑40 VDC (max 20 W).
