The document introduces a network camera called AXIS 225FD, which features anti-violence design, ultra-clear image quality, and PoE support. It is suitable for professional surveillance and remote monitoring. The camera has advanced alarm processing capabilities and security features, providing a perfect solution through the network.
This manual describes the Axis 225FD fixed dome network camera, a high‑performance, vandal‑proof device designed for professional surveillance in harsh environments. It covers the camera’s key features such as PoE power, dual video streams (M‑JPEG and MPEG‑4), varifocal lens, and advanced security functions including password protection, IP filtering, HTTPS encryption and IEEE 802.1X.
The guide also provides technical specifications, installation instructions, wiring diagrams, and information on external interfaces, alarm inputs/outputs, and software integration. Details on environmental ratings, power options, and firmware upgrade procedures are included to help installers and users configure and maintain the camera effectively. This manual is written in Chinese.
| Maximum resolution | 640×480 (VGA) |
|---|---|
| Maximum frame rate | 30 fps |
| Lens type | Varifocal 2.8–5.8 mm, DC‑iris |
| Minimum illumination (color) | 1 lux (F1.4) |
| Processor | ETRAX 100LX |
| Memory | 32 MB RAM, 8 MB Flash |
| Operating temperature (without heater) | -20 °C to 50 °C |
| Power options | PoE (IEEE 802.3af) or 9‑24 V DC/AC |
| Alarm inputs / outputs | 2 inputs, 1 output |
The camera can be powered via Power over Ethernet (IEEE 802.3af) or with an external 9‑24 V DC/AC supply.
The Axis 225FD provides two alarm inputs and one alarm output.
The camera needs at least 1 lux of illumination in color mode (F1.4).
It supports Motion JPEG and MPEG‑4 (Part 2) video streams.
