AXIS P3301/-V fixed dome network cameras provide excellent video quality, multiple H.264 streams, a concealed and compact design, intelligent video functionality, Power over Ethernet, advanced security and network management and ONVIF support
This manual describes the Axis P3301 and P3301‑V fixed‑hemisphere network cameras, which are designed for covert indoor video surveillance in high‑risk environments such as retail stores, schools, prisons, banks and airports. It covers the camera’s hardware features, video and audio capabilities, network settings, and security functions.
The document includes technical specifications, optional accessories, installation instructions, and information on smart video analytics, ONVIF compatibility, and power over Ethernet (PoE) operation. It also provides details on environmental limits, certifications, and warranty accessories. This manual is written in Chinese.
| Image sensor | ¼" progressive scan RGB VGA CMOS |
|---|---|
| Lens | 2.8‑10 mm, F1.3, DC aperture |
| Horizontal view angle | 23°‑72° |
| Minimum illumination | 1 lux at F1.3 |
| Shutter speed | 1/20000 s to 1/4 s |
| Power supply | 4.9‑5.1 V DC, max 4 W |
| Power over Ethernet | IEEE 802.3af Class 2 PoE |
| Weight (P3301) | 425 g (0.94 lb) |
| Weight (P3301‑V) | 580 g (1.28 lb) |
| Video compression | H.264 and Motion JPEG |
The camera supports H.264 and Motion JPEG video compression.
Yes, it can be powered via IEEE 802.3af Power over Ethernet (Class 2).
The camera needs at least 1 lux at an aperture of F1.3.
Yes, the camera supports the ONVIF specification for interoperability.
