The AT‑FS700 series provides fast Ethernet switching with 8, 16 or 24 ports, auto‑MDI/MDIX, full/half‑duplex flow control and low power consumption, making it suitable for enterprise, government and educational networks. The series includes models AT‑FS708L (8‑port), AT‑FS716L (16‑port) and AT‑FS724L (24‑port).
Key specifications include 10/100 Mbps ports, a 4 K MAC address table, up to 148 800 packets per second at 100 Mbps, and optional rack‑mount accessories. Power requirements are 100‑240 V AC, 50‑60 Hz, and the devices meet certifications such as FCC, CE and UL. This manual is written in Chinese.
| Port speed | 10/100 Mbps |
|---|---|
| Auto MDI/MDIX | Supported on all ports |
| Full/Half‑duplex flow control | Supported |
| Power input | 100‑240 V AC, 50‑60 Hz |
| MAC address table size | 4 K entries |
| Maximum packet rate (100 Mbps) | 148 800 packets/s |
| Switching buffer (FS708L) | 256 KB |
| Dimensions (AT‑FS708L) | 160 × 101 × 30 mm |
| Weight (AT‑FS708L) | 0.55 kg |
| Certifications (AT‑FS708L) | FCC/EN55022 Class A, VCCI Class A |
The AT‑FS708L provides 8 10/100 Mbps Ethernet ports.
It operates from 100‑240 V AC at 50‑60 Hz.
Yes, all ports have auto‑MDI/MDIX capability.
It complies with FCC/EN55022 Class A and VCCI Class A standards.
