DAM-E3046 Manual. It introduces the main indicators, wiring methods, code configuration table, communication protocol and other contents of the product.
The DAM‑E3046 is a 6‑channel thermocouple input module designed for industrial data acquisition. The manual provides the terminal distribution diagram, main specifications, wiring connections, and code configuration tables needed for installation and setup.
It also includes an introduction to the MODBUS protocol, details on supported function codes, and instructions for EEPROM configuration, allowing users to integrate the module into Ethernet‑based control networks. This manual is written in Chinese.
| Input types | PT100, Cu50, Cu100, BA1, BA2, G53 |
|---|---|
| Sampling rate | 10 Hz |
| Resolution | 16 bit |
| Zero‑drift | ±3 µV/°C |
| Input impedance | 10 kΩ |
| CMRR @ 50/60 Hz | 150 dB |
| Isolation voltage | 3000 V |
| Power supply | +10 V to +30 V DC |
It samples data at 10 Hz.
The isolation voltage is rated at 3000 V.
